Features
- Pitch: 5,08 mm
- Connection system: pcb
- Plastic body: PA66, UL 94V0
- Temperature: -40°C + 105°C
- Rated voltage: 450V
- Rated current: 20A
- Wire section: 2,5 mm2 22÷12 AWG
-
Approvals
15A-320V
15A-300V
| Product code | Poles | |
|---|---|---|
| CCM02-5.08-VF | 2 Poles | Datasheet 3D Contact us |
| CCM03-5.08-VF | 3 Poles | Datasheet 3D Contact us |
| CCM04-5.08-VF | 4 Poles | Datasheet 3D Contact us |
| CCM05-5.08-VF | 5 Poles | Datasheet 3D Contact us |
| CCM06-5.08-VF | 6 Poles | Datasheet 3D Contact us |
| CCM07-5.08-VF | 7 Poles | Datasheet 3D Contact us |
| CCM08-5.08-VF | 8 Poles | Datasheet 3D Contact us |
| CCM09-5.08-VF | 9 Poles | Datasheet 3D Contact us |
| CCM10-5.08-VF | 10 Poles | Datasheet 3D Contact us |
| CCM11-5.08-VF | 11 Poles | Datasheet 3D Contact us |
| CCM12-5.08-VF | 12 Poles | Datasheet 3D Contact us |
| CCM13-5.08-VF | 13 Poles | Datasheet 3D Contact us |
| CCM14-5.08-VF | 14 Poles | Datasheet 3D Contact us |
| CCM15-5.08-VF | 15 Poles | Datasheet 3D Contact us |
| CCM16-5.08-VF | 16 Poles | Datasheet 3D Contact us |
| CCM17-5.08-VF | 17 Poles | Datasheet 3D Contact us |
| CCM18-5.08-VF | 18 Poles | Datasheet 3D Contact us |
| CCM19-5.08-VF | 19 Poles | Datasheet 3D Contact us |
| CCM20-5.08-VF | 20 Poles | Datasheet 3D Contact us |
| CCM21-5.08-VF | 21 Poles | Datasheet 3D Contact us |
| CCM22-5.08-VF | 22 Poles | Datasheet 3D Contact us |
