Features
- Pitch: 3,81 mm
- Connection system: pcb
- Plastic body: PA66, UL 94V0
- Temperature: -40°C + 105°C
- Rated voltage: 250V
- Rated current: 7A
- Wire section: 1,5 sqmm 28÷16 AWG
-
Approvals
8A-300V
| Product code | Poles | |
|---|---|---|
| CMD2-3.81-HF | 2 Poles | Datasheet Contact us |
| CMD3-3.81-HF | 3 Poles | Datasheet Contact us |
| CMD4-3.81-HF | 4 Poles | Datasheet Contact us |
| CMD5-3.81-HF | 5 Poles | Datasheet Contact us |
| CMD6-3.81-HF | 6 Poles | Datasheet Contact us |
| CMD7-3.81-HF | 7 Poles | Datasheet Contact us |
| CMD8-3.81-HF | 8 Poles | Datasheet Contact us |
| CMD9-3.81-HF | 9 Poles | Datasheet Contact us |
| CMD10-3.81-HF | 10 Poles | Datasheet Contact us |
| CMD11-3.81-HF | 11 Poles | Datasheet Contact us |
| CMD12-3.81-HF | 12 Poles | Datasheet Contact us |
| CMD13-3.81-HF | 13 Poles | Datasheet Contact us |
| CMD14-3.81-HF | 14 Poles | Datasheet Contact us |
| CMD15-3.81-HF | 15 Poles | Datasheet Contact us |
| CMD16-3.81-HF | 16 Poles | Datasheet Contact us |
| CMD17-3.81-HF | 17 Poles | Datasheet Contact us |
| CMD18-3.81-HF | 18 Poles | Datasheet Contact us |
| CMD19-3.81-HF | 19 Poles | Datasheet Contact us |
| CMD20-3.81-HF | 20 Poles | Datasheet Contact us |
| CMD21-3.81-HF | 21 Poles | Datasheet Contact us |
| CMD22-3.81-HF | 22 Poles | Datasheet Contact us |
