Features
- Pitch: 3,81 mm
- Connection system: pcb
- Plastic body: PA66, UL 94V0
- Temperature: -40°C + 105°C
- Rated voltage: 250V
- Rated current: 7A
- Wire section: 1,5 mm2 28÷16 AWG
-
Approvals
8A-300V
| Product code | Poles | |
|---|---|---|
| CMD02-3.81-VF | 2 Poles | Datasheet Contact us |
| CMD03-3.81-VF | 3 Poles | Datasheet Contact us |
| CMD04-3.81-VF | 4 Poles | Datasheet Contact us |
| CMD05-3.81-VF | 5 Poles | Datasheet Contact us |
| CMD06-3.81-VF | 6 Poles | Datasheet Contact us |
| CMD07-3.81-VF | 7 Poles | Datasheet Contact us |
| CMD08-3.81-VF | 8 Poles | Datasheet Contact us |
| CMD09-3.81-VF | 9 Poles | Datasheet Contact us |
| CMD10-3.81-VF | 10 Poles | Datasheet Contact us |
| CMD11-3.81-VF | 11 Poles | Datasheet Contact us |
| CMD12-3.81-VF | 12 Poles | Datasheet Contact us |
| CMD13-3.81-VF | 13 Poles | Datasheet Contact us |
| CMD14-3.81-VF | 14 Poles | Datasheet Contact us |
| CMD15-3.81-VF | 15 Poles | Datasheet Contact us |
| CMD16-3.81-VF | 16 Poles | Datasheet Contact us |
| CMD17-3.81-VF | 17 Poles | Datasheet Contact us |
| CMD18-3.81-VF | 18 Poles | Datasheet Contact us |
| CMD19-3.81-VF | 19 Poles | Datasheet Contact us |
| CMD20-3.81-VF | 20 Poles | Datasheet Contact us |
| CMD21-3.81-VF | 21 Poles | Datasheet Contact us |
| CMD22-3.81-VF | 22 Poles | Datasheet Contact us |
