Features
- Pitch: 5,08 mm
- Connection system: pcb
- Plastic body: PA66, UL 94V0
- Temperature: -40°C + 105°C
- Rated voltage: 450V
- Rated current: 20A
- Wire section: 2,5 mm2 22÷12 AWG
-
Approvals
15A-300V
| Product code | Poles | |
|---|---|---|
| CMD02-5.08-H | 2 Poles | Datasheet Contact us |
| CMD03-5.08-H | 3 Poles | Datasheet Contact us |
| CMD04-5.08-H | 4 Poles | Datasheet Contact us |
| CMD05-5.08-H | 5 Poles | Datasheet Contact us |
| CMD06-5.08-H | 6 Poles | Datasheet Contact us |
| CMD07-5.08-H | 7 Poles | Datasheet Contact us |
| CMD08-5.08-H | 8 Poles | Datasheet Contact us |
| CMD09-5.08-H | 9 Poles | Datasheet Contact us |
| CMD10-5.08-H | 10 Poles | Datasheet Contact us |
| CMD11-5.08-H | 11 Poles | Datasheet Contact us |
| CMD12-5.08-H | 12 Poles | Datasheet Contact us |
| CMD13-5.08-H | 13 Poles | Datasheet Contact us |
| CMD14-5.08-H | 14 Poles | Datasheet Contact us |
| CMD15-5.08-H | 15 Poles | Datasheet Contact us |
| CMD16-5.08-H | 16 Poles | Datasheet Contact us |
| CMD17-5.08-H | 17 Poles | Datasheet Contact us |
| CMD18-5.08-H | 18 Poles | Datasheet Contact us |
| CMD19-5.08-H | 19 Poles | Datasheet Contact us |
| CMD20-5.08-H | 20 Poles | Datasheet Contact us |
| CMD21-5.08-H | 21 Poles | Datasheet Contact us |
| CMD22-5.08-H | 22 Poles | Datasheet Contact us |
