Features
- Pitch: 2,5 mm
- Connection system: pcb
- Plastic body: PA66, UL 94V0
- Temperature: -40°C + 105°C
- Rated voltage: 130V
- Rated current: 6A
- Wire section: 1,5 mm2 28÷16 AWG
-
Approvals
5A-150V
| Product code | Poles | |
|---|---|---|
| MDL02-2.5-H | 2 Poles | Datasheet Contact us |
| MDL03-2.5-H | 3 Poles | Datasheet Contact us |
| MDL04-2.5-H | 4 Poles | Datasheet Contact us |
| MDL05-2.5-H | 5 Poles | Datasheet Contact us |
| MDL06-2.5-H | 6 Poles | Datasheet Contact us |
| MDL07-2.5-H | 7 Poles | Datasheet Contact us |
| MDL08-2.5-H | 8 Poles | Datasheet Contact us |
| MDL09-2.5-H | 9 Poles | Datasheet Contact us |
| MDL10-2.5-H | 10 Poles | Datasheet Contact us |
| MDL11-2.5-H | 11 Poles | Datasheet Contact us |
| MDL12-2.5-H | 12 Poles | Datasheet Contact us |
| MDL13-2.5-H | 13 Poles | Datasheet Contact us |
| MDL14-2.5-H | 14 Poles | Datasheet Contact us |
| MDL15-2.5-H | 15 Poles | Datasheet Contact us |
| MDL16-2.5-H | 16 Poles | Datasheet Contact us |
| MDL17-2.5-H | 17 Poles | Datasheet Contact us |
| MDL18-2.5-H | 18 Poles | Datasheet Contact us |
| MDL19-2.5-H | 19 Poles | Datasheet Contact us |
| MDL20-2.5-H | 20 Poles | Datasheet Contact us |
| MDL21-2.5-H | 21 Poles | Datasheet Contact us |
| MDL22-2.5-H | 22 Poles | Datasheet Contact us |
| MDL23-2.5-H | 23 Poles | Datasheet Contact us |
| MDL24-2.5-H | 24 Poles | Datasheet Contact us |
