Features
- Pitch: 3,5 mm
- Connection system: pcb
- Plastic body: PA66, UL 94V0
- Temperature: -40°C + 105°C
- Rated voltage: 250V
- Rated current: 7A
- Wire section: 1,5 sqmm 28÷16 AWG
-
Approvals
8A-300V
| Product code | Poles | |
|---|---|---|
| MDL2-3.5-V | 2 Poles | Datasheet Contact us |
| MDL3-3.5-V | 3 Poles | Datasheet Contact us |
| MDL4-3.5-V | 4 Poles | Datasheet Contact us |
| MDL5-3.5-V | 5 Poles | Datasheet Contact us |
| MDL6-3.5-V | 6 Poles | Datasheet Contact us |
| MDL7-3.5-V | 7 Poles | Datasheet Contact us |
| MDL8-3.5-V | 8 Poles | Datasheet Contact us |
| MDL9-3.5-V | 9 Poles | Datasheet Contact us |
| MDL10-3.5-V | 10 Poles | Datasheet Contact us |
| MDL11-3.5-V | 11 Poles | Datasheet Contact us |
| MDL12-3.5-V | 12 Poles | Datasheet Contact us |
| MDL13-3.5-V | 13 Poles | Datasheet Contact us |
| MDL14-3.5-V | 14 Poles | Datasheet Contact us |
| MDL15-3.5-V | 15 Poles | Datasheet Contact us |
| MDL16-3.5-V | 16 Poles | Datasheet Contact us |
| MDL17-3.5-V | 17 Poles | Datasheet Contact us |
| MDL18-3.5-V | 18 Poles | Datasheet Contact us |
| MDL19-3.5-V | 19 Poles | Datasheet Contact us |
| MDL20-3.5-V | 20 Poles | Datasheet Contact us |
| MDL21-3.5-V | 21 Poles | Datasheet Contact us |
| MDL22-3.5-V | 22 Poles | Datasheet Contact us |
| MDL23-3.5-V | 23 Poles | Datasheet Contact us |
| MDL24-3.5-V | 24 Poles | Datasheet Contact us |
