Features
- Pitch: 3,81 mm
- Connection system: pcb
- Plastic body: PA66, UL 94V0
- Temperature: -40°C + 105°C
- Rated voltage: 250V
- Rated current: 7A
- Wire section: 1,5 mm2 28÷16 AWG
-
Approvals
8A-300V
| Product code | Poles | |
|---|---|---|
| MDL02-3.81-VF | 2 Poles | Datasheet Contact us |
| MDL03-3.81-VF | 3 Poles | Datasheet Contact us |
| MDL04-3.81-VF | 4 Poles | Datasheet Contact us |
| MDL05-3.81-VF | 5 Poles | Datasheet Contact us |
| MDL06-3.81-VF | 6 Poles | Datasheet Contact us |
| MDL07-3.81-VF | 7 Poles | Datasheet Contact us |
| MDL08-3.81-VF | 8 Poles | Datasheet Contact us |
| MDL09-3.81-VF | 9 Poles | Datasheet Contact us |
| MDL10-3.81-VF | 10 Poles | Datasheet Contact us |
| MDL11-3.81-VF | 11 Poles | Datasheet Contact us |
| MDL12-3.81-VF | 12 Poles | Datasheet Contact us |
| MDL13-3.81-VF | 13 Poles | Datasheet Contact us |
| MDL14-3.81-VF | 14 Poles | Datasheet Contact us |
| MDL15-3.81-VF | 15 Poles | Datasheet Contact us |
| MDL16-3.81-VF | 16 Poles | Datasheet Contact us |
| MDL17-3.81-VF | 17 Poles | Datasheet Contact us |
| MDL18-3.81-VF | 18 Poles | Datasheet Contact us |
| MDL19-3.81-VF | 19 Poles | Datasheet Contact us |
| MDL20-3.81-VF | 20 Poles | Datasheet Contact us |
| MDL21-3.81-VF | 21 Poles | Datasheet Contact us |
| MDL22-3.81-VF | 22 Poles | Datasheet Contact us |
