Features
- Pitch: 5 mm
- Connection system: pcb
- Plastic body: PA66, UL 94V0
- Temperature: -40°C + 105°C
- Rated voltage: 450V
- Rated current: 20A
- Wire section: 2,5 mm2 22÷12 AWG
-
Approvals
15A-300V
| Product code | Poles | |
|---|---|---|
| MDL02-5-V | 2 Poles | Datasheet Contact us |
| MDL03-5-V | 3 Poles | Datasheet Contact us |
| MDL04-5-V | 4 Poles | Datasheet Contact us |
| MDL05-5-V | 5 Poles | Datasheet Contact us |
| MDL06-5-V | 6 Poles | Datasheet Contact us |
| MDL07-5-V | 7 Poles | Datasheet Contact us |
| MDL08-5-V | 8 Poles | Datasheet Contact us |
| MDL09-5-V | 9 Poles | Datasheet Contact us |
| MDL10-5-V | 10 Poles | Datasheet Contact us |
| MDL11-5-V | 11 Poles | Datasheet Contact us |
| MDL12-5-V | 12 Poles | Datasheet Contact us |
| MDL13-5-V | 13 Poles | Datasheet Contact us |
| MDL14-5-V | 14 Poles | Datasheet Contact us |
| MDL15-5-V | 15 Poles | Datasheet Contact us |
| MDL16-5-V | 16 Poles | Datasheet Contact us |
| MDL17-5-V | 17 Poles | Datasheet Contact us |
| MDL18-5-V | 18 Poles | Datasheet Contact us |
| MDL19-5-V | 19 Poles | Datasheet Contact us |
| MDL20-5-V | 20 Poles | Datasheet Contact us |
| MDL21-5-V | 21 Poles | Datasheet Contact us |
| MDL22-5-V | 22 Poles | Datasheet Contact us |
| MDL23-5-V | 23 Poles | Datasheet Contact us |
| MDL24-5-V | 24 Poles | Datasheet Contact us |
