Features
- Pitch: 3,5 mm
- Connection system: molla
- Plastic body: PA66, UL 94V0
- Temperature: -40°C + 105°C
- Rated voltage: 130V
- Rated current: 10A
- Wire section: 1,5 mm2 28÷14 AWG
-
Approvals
10A-300V
| Product code | Poles | |
|---|---|---|
| CFP102-3.5 | 2 Poles | Datasheet Contact us |
| CFP103-3.5 | 3 Poles | Datasheet Contact us |
| CFP104-3.5 | 4 Poles | Datasheet Contact us |
| CFP105-3.5 | 5 Poles | Datasheet Contact us |
| CFP106-3.5 | 6 Poles | Datasheet Contact us |
| CFP107-3.5 | 7 Poles | Datasheet Contact us |
| CFP108-3.5 | 8 Poles | Datasheet Contact us |
| CFP109-3.5 | 9 Poles | Datasheet Contact us |
| CFP110-3.5 | 10 Poles | Datasheet Contact us |
| CFP111-3.5 | 11 Poles | Datasheet Contact us |
| CFP112-3.5 | 12 Poles | Datasheet Contact us |
| CFP113-3.5 | 13 Poles | Datasheet Contact us |
| CFP114-3.5 | 14 Poles | Datasheet Contact us |
| CFP115-3.5 | 15 Poles | Datasheet Contact us |
| CFP116-3.5 | 16 Poles | Datasheet Contact us |
| CFP117-3.5 | 17 Poles | Datasheet Contact us |
| CFP118-3.5 | 18 Poles | Datasheet Contact us |
| CFP119-3.5 | 19 Poles | Datasheet Contact us |
| CFP120-3.5 | 20 Poles | Datasheet Contact us |
| CFP121-3.5 | 21 Poles | Datasheet Contact us |
| CFP122-3.5 | 22 Poles | Datasheet Contact us |
| CFP123-3.5 | 23 Poles | Datasheet Contact us |
| CFP124-3.5 | 24 Poles | Datasheet Contact us |
