Features
- Pitch: 5,08 mm
- Connection system: molla
- Plastic body: PA66, UL 94V0
- Temperature: -40°C + 105°C
- Rated voltage: 250V
- Rated current: 16A
- Wire section: 2,5 mm2 28÷12 AWG
-
Approvals
15A-300V
| Product code | Poles | |
|---|---|---|
| CFP102-5.08 | 2 Poles | Datasheet Contact us |
| CFP103-5.08 | 3 Poles | Datasheet Contact us |
| CFP104-5.08 | 4 Poles | Datasheet Contact us |
| CFP105-5.08 | 5 Poles | Datasheet Contact us |
| CFP106-5.08 | 6 Poles | Datasheet Contact us |
| CFP107-5.08 | 7 Poles | Datasheet Contact us |
| CFP108-5.08 | 8 Poles | Datasheet Contact us |
| CFP109-5.08 | 9 Poles | Datasheet Contact us |
| CFP110-5.08 | 10 Poles | Datasheet Contact us |
| CFP111-5.08 | 11 Poles | Datasheet Contact us |
| CFP112-5.08 | 12 Poles | Datasheet Contact us |
| CFP113-5.08 | 13 Poles | Datasheet Contact us |
| CFP114-5.08 | 14 Poles | Datasheet Contact us |
| CFP115-5.08 | 15 Poles | Datasheet Contact us |
| CFP116-5.08 | 16 Poles | Datasheet Contact us |
| CFP117-5.08 | 17 Poles | Datasheet Contact us |
| CFP118-5.08 | 18 Poles | Datasheet Contact us |
| CFP119-5.08 | 19 Poles | Datasheet Contact us |
| CFP120-5.08 | 20 Poles | Datasheet Contact us |
| CFP121-5.08 | 21 Poles | Datasheet Contact us |
| CFP122-5.08 | 22 Poles | Datasheet Contact us |
| CFP123-5.08 | 23 Poles | Datasheet Contact us |
| CFP124-5.08 | 24 Poles | Datasheet Contact us |
