Features
- Pitch: 5,08 mm
- Connection system: molla
- Plastic body: PA66, UL 94V0
- Temperature: -40°C + 105°C
- Rated voltage: 250V
- Rated current: 16A
- Wire section: 2,5 mm2 28÷12 AWG
-
Approvals
15A-300V
| Product code | Poles | |
|---|---|---|
| CFP302-5.08 | 2 Poles | Datasheet Contact us |
| CFP303-5.08 | 3 Poles | Datasheet Contact us |
| CFP304-5.08 | 4 Poles | Datasheet Contact us |
| CFP305-5.08 | 5 Poles | Datasheet Contact us |
| CFP306-5.08 | 6 Poles | Datasheet Contact us |
| CFP307-5.08 | 7 Poles | Datasheet Contact us |
| CFP308-5.08 | 8 Poles | Datasheet Contact us |
| CFP309-5.08 | 9 Poles | Datasheet Contact us |
| CFP310-5.08 | 10 Poles | Datasheet Contact us |
| CFP311-5.08 | 11 Poles | Datasheet Contact us |
| CFP312-5.08 | 12 Poles | Datasheet Contact us |
| CFP313-5.08 | 13 Poles | Datasheet Contact us |
| CFP314-5.08 | 14 Poles | Datasheet Contact us |
| CFP315-5.08 | 15 Poles | Datasheet Contact us |
| CFP316-5.08 | 16 Poles | Datasheet Contact us |
| CFP317-5.08 | 17 Poles | Datasheet Contact us |
| CFP318-5.08 | 18 Poles | Datasheet Contact us |
| CFP319-5.08 | 19 Poles | Datasheet Contact us |
| CFP320-5.08 | 20 Poles | Datasheet Contact us |
| CFP321-5.08 | 21 Poles | Datasheet Contact us |
| CFP322-5.08 | 22 Poles | Datasheet Contact us |
| CFP323-5.08 | 23 Poles | Datasheet Contact us |
| CFP324-5.08 | 24 Poles | Datasheet Contact us |
