Features
- Pitch: 7,5 mm
- Connection system: molla
- Plastic body: PA66, UL 94V0
- Temperature: -40°C + 105°C
- Rated voltage: 250V
- Rated current: 16A
- Wire section: 2,5 mm2 28÷12 AWG
-
Approvals
15A-300V
| Product code | Poles | |
|---|---|---|
| CFP402-7.5-SP | 2 Poles | Datasheet Contact us |
| CFP403-7.5-SP | 3 Poles | Datasheet Contact us |
| CFP404-7.5-SP | 4 Poles | Datasheet Contact us |
| CFP405-7.5-SP | 5 Poles | Datasheet Contact us |
| CFP406-7.5-SP | 6 Poles | Datasheet Contact us |
| CFP407-7.5-SP | 7 Poles | Datasheet Contact us |
| CFP408-7.5-SP | 8 Poles | Datasheet Contact us |
| CFP409-7.5-SP | 9 Poles | Datasheet Contact us |
| CFP410-7.5-SP | 10 Poles | Datasheet Contact us |
| CFP411-7.5-SP | 11 Poles | Datasheet Contact us |
| CFP412-7.5-SP | 12 Poles | Datasheet Contact us |
| CFP413-7.5-SP | 13 Poles | Datasheet Contact us |
| CFP414-7.5-SP | 14 Poles | Datasheet Contact us |
| CFP415-7.5-SP | 15 Poles | Datasheet Contact us |
| CFP416-7.5-SP | 16 Poles | Datasheet Contact us |
| CFP417-7.5-SP | 17 Poles | Datasheet Contact us |
| CFP418-7.5-SP | 18 Poles | Datasheet Contact us |
| CFP419-7.5-SP | 19 Poles | Datasheet Contact us |
| CFP420-7.5-SP | 20 Poles | Datasheet Contact us |
| CFP421-7.5-SP | 21 Poles | Datasheet Contact us |
| CFP422-7.5-SP | 22 Poles | Datasheet Contact us |
| CFP423-7.5-SP | 23 Poles | Datasheet Contact us |
| CFP424-7.5-SP | 24 Poles | Datasheet Contact us |
