Features
- Pitch: 3,81 mm
- Connection system: molla
- Plastic body: PA66, UL 94V0
- Temperature: -40°C + 105°C
- Rated voltage: 130V
- Rated current: 10A
- Wire section: 1,5 mm2 28÷14 AWG
-
Approvals
10A-300V
| Product code | Poles | |
|---|---|---|
| CMP102-3.81-CV | 2 Poles | Datasheet Contact us |
| CMP103-3.81-CV | 3 Poles | Datasheet Contact us |
| CMP104-3.81-CV | 4 Poles | Datasheet Contact us |
| CMP105-3.81-CV | 5 Poles | Datasheet Contact us |
| CMP106-3.81-CV | 6 Poles | Datasheet Contact us |
| CMP107-3.81-CV | 7 Poles | Datasheet Contact us |
| CMP108-3.81-CV | 8 Poles | Datasheet Contact us |
| CMP109-3.81-CV | 9 Poles | Datasheet Contact us |
| CMP110-3.81-CV | 10 Poles | Datasheet Contact us |
| CMP111-3.81-CV | 11 Poles | Datasheet Contact us |
| CMP112-3.81-CV | 12 Poles | Datasheet Contact us |
| CMP113-3.81-CV | 13 Poles | Datasheet Contact us |
| CMP114-3.81-CV | 14 Poles | Datasheet Contact us |
| CMP115-3.81-CV | 15 Poles | Datasheet Contact us |
| CMP116-3.81-CV | 16 Poles | Datasheet Contact us |
| CMP117-3.81-CV | 17 Poles | Datasheet Contact us |
| CMP118-3.81-CV | 18 Poles | Datasheet Contact us |
| CMP119-3.81-CV | 19 Poles | Datasheet Contact us |
| CMP120-3.81-CV | 20 Poles | Datasheet Contact us |
| CMP121-3.81-CV | 21 Poles | Datasheet Contact us |
| CMP122-3.81-CV | 22 Poles | Datasheet Contact us |
| CMP123-3.81-CV | 23 Poles | Datasheet Contact us |
| CMP124-3.81-CV | 24 Poles | Datasheet Contact us |
