Features
- Pitch: 5 mm
- Connection system: vite
- Plastic body: PA66, UL 94V0
- Temperature: -40°C + 105°C
- Rated voltage: 250V
- Rated current: 24A
- Wire section: 2,5 mm2 26÷14 AWG
-
Approvals
15A-300V
| Product code | Poles | |
|---|---|---|
| MLR512-5-V | 2 Poles | Datasheet Contact us |
| MLR513-5-V | 3 Poles | Datasheet Contact us |
| MLR514-5-V | 4 Poles | Datasheet Contact us |
| MLR515-5-V | 5 Poles | Datasheet Contact us |
| MLR516-5-V | 6 Poles | Datasheet Contact us |
| MLR517-5-V | 7 Poles | Datasheet Contact us |
| MLR518-5-V | 8 Poles | Datasheet Contact us |
| MLR519-5-V | 9 Poles | Datasheet Contact us |
| MLR5110-5-V | 10 Poles | Datasheet Contact us |
| MLR5111-5-V | 11 Poles | Datasheet Contact us |
| MLR5112-5-V | 12 Poles | Datasheet Contact us |
| MLR5113-5-V | 13 Poles | Datasheet Contact us |
| MLR5114-5-V | 14 Poles | Datasheet Contact us |
| MLR5115-5-V | 15 Poles | Datasheet Contact us |
| MLR5116-5-V | 16 Poles | Datasheet Contact us |
| MLR5117-5-V | 17 Poles | Datasheet Contact us |
| MLR5118-5-V | 18 Poles | Datasheet Contact us |
| MLR5119-5-V | 19 Poles | Datasheet Contact us |
| MLR5120-5-V | 20 Poles | Datasheet Contact us |
| MLR5121-5-V | 21 Poles | Datasheet Contact us |
| MLR5122-5-V | 22 Poles | Datasheet Contact us |
| MLR5123-5-V | 23 Poles | Datasheet Contact us |
| MLR5124-5-V | 24 Poles | Datasheet Contact us |
